UNIVIEW XVR301-16G3 16-Channel H.265 Hybrid XVR DVR
Upgrade Your CCTV System Today
Get reliable, flexible surveillance recording with the UNIVIEW XVR301-16G3 16-Channel Hybrid XVR.
With support for multiple camera technologies, H.265 compression, coaxial audio, IP camera expansion, and up to 8TB HDD storage, it’s built to handle demanding CCTV installations.
UNIVIEW XVR301-16G3 16-Channel H.265 Hybrid XVR DVR
Flexible, Reliable CCTV Recording
Secure your property with the UNIVIEW XVR301-16G3, a versatile 16-channel hybrid video recorder built for modern CCTV surveillance systems.
Flexible Camera Support
- 16 BNC analog inputs — supports TVI, AHD, CVI, and CVBS cameras
- IP camera support for system expansion
- Up to 8 IP channels, or up to 16 after analog-camera conversion
Efficient Recording
H.265/H.264 video compression helps optimize storage use and network bandwidth. For compatible TVI cameras, audio can travel over the same coaxial cable, simplifying installation.
Local Viewing and Remote Access
- HDMI and VGA outputs — up to 1920 × 1080
- Remote network connectivity with P2P access
- ONVIF/RTSP compatibility for broader integration
Smarter Detection
- Motion detection
- Uniview’s Ultra Motion Detection (UMD) on up to 8 analog channels
Storage and Where It Fits
One SATA interface supports up to 8 TB per HDD. The XVR301-16G3 suits homes, offices, shops, warehouses, schools, and other CCTV installations.
Key Features
- Hybrid 16-channel input — mix AHD, TVI, CVI, CVBS analog and IP cameras on one recorder
- H.265/H.264 compression — efficient storage without sacrificing image quality
- Audio over coax — video and audio travel on the same cable for TVI cameras
- Simultaneous HDMI + VGA output — connect two displays at once
- Up to 8TB storage support — extended continuous recording on a single drive
- Two-way audio — communicate through compatible cameras
- USB backup and remote playback — export footage easily and view from anywhere
- Compact, easy-mount design — fits tight installation spaces
Technical Specifications
| Specification | Details |
|---|---|
| Brand | UNIVIEW |
| Model | XVR301-16G3 |
| Product Type | Hybrid XVR / Digital Video Recorder |
| Video Compression | H.265 / H.264 |
| Analog Video Inputs | 16 × BNC |
| IP Video Inputs | 8 channels |
| Maximum IP Channels | Up to 16 after analog-camera conversion |
| Analog Camera Support | TVI, AHD, CVI, CVBS |
| AHD Support | Up to 5MP @ 12fps, 4MP @ 15fps, 1080P @ 30fps, 720P @ 30fps |
| TVI Support | Up to 5MP @ 12fps, 4MP @ 15fps, 1080P @ 30fps, 720P @ 30fps |
| CVI Support | Up to 1080P @ 30fps, 720P @ 30fps |
| CVBS | Supported |
| Audio Input | 1 × RCA |
| Audio Output | 1 × RCA |
| Audio Compression | G.711U |
| Audio over Coax | Supported for TVI cameras |
| HDMI Output | Up to 1920 × 1080 |
| VGA Output | Up to 1920 × 1080 |
| Synchronous Playback | HD: 8-channel; SD: 16-channel |
| Recording Resolution | 5MP Lite, 4MP Lite, 1080P Lite, 720P, D1, CIF |
| Recording Frame Rate | 5MP Lite @ 6fps; 4MP Lite @ 8fps; 1080P Lite @ 12fps; 720P @ 12fps |
| IP Decoding | 1 × 8MP @ 30fps; 2 × 4MP @ 30fps; 4 × 1080P @ 30fps |
| HDD Interface | 1 × SATA |
| Maximum HDD Capacity | Up to 8TB per HDD |
| Incoming Bandwidth | 40Mbps; up to 56Mbps after analog-camera conversion |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | Up to 128 |
| Network Interface | 1 × RJ45 10/100Mbps Ethernet |
| USB | 2 × USB 2.0 |
| RS485 | 1 × RS485 |
| Protocols | TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP |
| Motion Detection | Supported |
| Ultra Motion Detection | UMD for up to 8 analog channels |
| Power Supply | 12V DC |
| Power Consumption | ≤10W without HDD |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | ≤90% RH, non-condensing |
| Dimensions | 260 × 226 × 47mm |
| Weight | < 1.1 kg without HDD |
| Certifications | CE, FCC, UL, RoHS, WEEE |
