TP-Link CPE610 5 GHz 23dBi Outdoor CPE
TP-Link CPE610 5 GHz 23dBi Outdoor CPE Product details CPE610 5 GHz 23dBi Outdoor CPE Directional Antenna The TP-Link CPE610 is an outdoor wireless device designed to […]
TP-Link CPE610 5 GHz 23dBi Outdoor CPE
Product details
CPE610 5 GHz 23dBi Outdoor CPE Directional Antenna
The TP-Link CPE610 is an outdoor wireless device designed to send internet signals over long distances using a 5 GHz frequency. It has a built-in 23dBi directional antenna, which means it focuses the signal in one direction for better range and performance. It’s ideal for point-to-point or point-to-multipoint connections—like linking two buildings or delivering internet from a central tower to remote locations. It supports speeds up to 300 Mbps, and it’s weatherproof (IP65 rated), making it suitable for outdoor use in harsh conditions. It uses PoE (Power over Ethernet) for easy installation, and it includes advanced features to reduce interference and improve performance over long distances. With a narrow beamwidth, it provides a focused, stable signal over up to 30 km (line of sight).
Specifications
| HARDWARE FEATURES | |
| Processor | Qualcomm 560MHz CPU, MIPS 74Kc |
| Memory | 64MB DDR2 RAM, 8MB Flash |
| Interface | 1 10/100Mbps Shielded Ethernet Port (LAN/POE) |
| Power Supply | Passive PoE, 16-27VDC, 7.41 W |
| Dimensions | 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) |
| Antenna Gain | 23dBi |
| Antenna Beamwidth | 9°(Azimuth), 7°(Elevation) |
| Protection | 15KV ESD, 6KV Lightning |
| Enclosure | Outdoor PC stabilized plastic, IP65 |
| WIRELESS FEATURES | |
| Wireless Standards | IEEE 802.11a/n |
| Proprietary Protocol | TDMA Mode (Pharos MAXtream enabled) |
| Wireless Speeds | Up to 300Mbps (40MHz, Dynamic) |
| Frequency | 5.15~5.85GHz |
| Transmit Power | Max. 25dBm (Adjustable by 1dBm) |
| SOFTWARE FEATURES | |
| Network Configuration | WAN/LAN: Static/Dynamic/PPPoE/L2TP/PPTP |
| Security | Firewall, Access Control, WPA/WPA2 |
| Wireless Configurations | MAXtream TDMA, Channel Width, DFS, WDS, Encryption |
| Management | Pharos Control, Web-based, SNMP, DDNS, SSH |
| System Tools | Indicators, Monitors, Spectrum Analyzer, Speed Test |
| POE ADAPTER FEATURES | |
| Dimensions | 85.8×43.9×29.7 mm |
| Interfaces | AC Jack, 2x 10/100Mbps Shielded Ethernet Ports |
| Power Status LEDs | Green |
| Input | 100-240VAC, 50/60Hz |
| Output | 24VDC, 0.5A Max, +4, 5pins; -7, 8pins (Support up to 60m) |
| Efficiency | >84.29% |
| Certifications | CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark |
| OTHERS | |
| Certification | CE, FCC, IC, RoHS, IP65 |
| Package Contents | Outdoor Wireless CPE, PoE Adapter, Mounting Straps, Cord |
| System Requirements | Windows, MAC OS, NetWare, UNIX, Linux |
| Environment | Operating Temperature: -40℃~70℃, Humidity: 10%~90% |
| Storage Temperature: -40℃~70℃, Humidity: 5%~95% | |
